CONSTRUCTION GENERAL

• Hand laid-up FRP hull w/PVC core sandwich construction above waterline and vinylester barrier lamination for osmosis protection
• Hand laid-up FRP deck/house and flybridge with PVC rigid foam sandwich construction
• Full length longitudinal engine stringers and athwartship stringers
• Windows with 3/8" tempered glass in salon, 1/2" in pilothouse
• Rub rails with stainless steel capping
• Bilge area finished smooth and coated with bright white epoxy paint
• Built-in swim platform w/stainless steel swim ladder and rail
• Quite Roll integrated spray rail system
• FRP hardtop over flybridge
• 5' sports cockpit
• 1' swim platform extension

ENGINE DETAILS

• Twin Caterpillar C-9 Acert (503 bhp) diesel engines with ZF transmissions and electronic instruments for dual stations

PORT

• Engine Hours: 6,192
• Lifetime fuel consumption: 27,404 gallons
• Cat C-9 “D” Rated recommends 78,000 gallons of fuel consumption prior to rebuild
• 65% of engine life remaining before rebuild

STARBOARD

• Engine hours: 6,191
• Lifetime fuel consumption: 26,893 gallons
• Cat C-9  “D” Rated recommends 78,000 gallons of fuel consumption prior to rebuild
• 65% of engine life remaining before rebuild

MECHANICAL

• Northern Lights 16kw generator w/sound shield & upgrade addition- 12kw Northern Lights generator w/sound shield
• 16 hp ABT bow and stern thrusters
• Chilled water A/C system
• ABT Trac 220 stabilizers w/6.0 sq.ft. fins and dual station controls
• Ball-valve bronze seacocks on all through-hulls below waterline
• Emergency tiller lock mechanism
• Evolution anti-vibration system with soft engine mounts
• Fiberglass drip pans under engines
• Glendinning hydraulic engine controls for dual stations
• Northern Lights water-sep exhaust system
• Hydraulic windlass w/handheld remote on foredeck
• Oil change pump for engines and generator
• Racor 75/1000 max dual fuel filters for main engines
• Racor 75/1000 max single fuel filters for generators
• Second dripless shaft bearing
• Stainless steel prop shafts (2) and Nibral props (2)
• Stainless steel rudders with bearings
• Stainless steel struts with bearings
• Tides packless shaft seals with one (1) spare seal for each shaft
• Under water exhaust system w/bypass and FRP mufflers
• Groco SPO80R 24v fuel transfer system
• Spare set ZF propellers stored in lazarete

ELECTRICAL SYSTEM

• Main electric distribution panel with gauges and circuit breakers for 230/115v ac and 24/12v dc system
• Accessible wiring raceway throughout
• Batteries in FRP boxes:
• Two (2) engine banks w/two AGM 8d-225ah batteries for each bank
• One (1) house bank w/four 8d-225ah batteries
• One (1) generator bank w/one 220ah battery
• Battery chargers - one (1) 24v and one (1) 12v
• Battery isolators two (2)
• Blowers in engine room - two (2) 115v ac and two (2) 24v dc
• Blowers for head ventilation - two (2) 24v dc
• Converter - 24v dc to 12v dc
• Compasses - two (2) Danforth 4" magnetic
• Copper bonding system to all underwater fittings with additional zinc anodes
• Electrical outlets - 115v ac throughout, gf outlets for heads and exterior
• engine battery interconnection system
• Glendinning 50amp cablemaster 2/75' of cable on transom w/additional 50 amp shore power inlet
• Inlet for TV/cable, phone on transom
• Inverter - Trace 2.5kw (24v dc to 115v ac)
• Isolation transformers 50amp - two (2)
• Kahlenburg D-OA dual trumpet air horn with compressor
• Lights - 24v dc chartlight
• Lights - 24v dc courtsey/step lights throughout and automatic in wardrobe
• lights - 24v dc overhead halogen fixtures throughout
• Lights - 24v dc rope style valance at salon and staterooms
• Lights for engine room - 115v ac flourescent and 24v dc
• Lights - Aqua Signal navigation set of five (5)
• Transom LED lights
• 4 underwater LED lights beneath swim platform
• Search light: ACR model 100D 24v dc with dual station controls
• Prop shaft brushes - two (2)
• Shoreline power transfer rotary switches

PLUMBING AND TANKAGE

• Bilge High water alarm system w/ warning panel at pilothouse
• Bilge pump in engine room-one (1) manual
• Bilge pumps - four (4) automatic 24v dc and emergency bilge suction on engine
• Cleanout and gauge for all tanks
• Faucets - Grohe single level mixing taps for sinks at galley, head and shower
• Fresh water faucet in engine room
• Fresh water pump, Headhunter model XR-124 with accumulator tank, 24v dc
• Fuel manifold system S/S (supply & return)
• Rigid fresh water pipes and color coded copper fuel lines
• Shore water inlet on transom
• Shower sump pumps - two (2) automatic 24v dc
• Tank gauge for fuel and water tanks
• Tankage - fuel tanks two (2) total capacity 1000 gallons, aluminum
• Tankage - holding tank capacity: 100 gallons FRP with macerator pump
• Tankage - water tank capacity: 300 gallons - stainless steel
• Toilets - two (2) Tecma 24v electric marine with y-valves and sanitary hose for all discharge plumbing
• Transom shower in recessed box with hot and cold supply
• Wash down outlets fresh water on fore deck, aft deck and flybridge
• Wash down salt water pump w/outlet on foredeck
• Water heater w/heat exchanger 115v ac 20 gallons
• Village 220 volt  800 GPD water maker

ENGINE ROOM

• Acoustically insulated, lined with sound absorbing material
• Cleanout and sight gauge for fuel tanks
• Edura coin dot flooring in engine room
• Fireboy fire suppression system including both intake and outlet air shutdown system with aluminum louvers
• Fresh water hose bib
• Lights - 115v ac fluorescent and 24v dc
• Outlets - 115v ac gf with water proof cover
• Stainless steel safety rails around engines and transmissions
• Two watertight bulkheads
• Watertight aluminum engine room doors w/sight windows

EXTERIOR IN GENERAL

• Bottom - two coats of black antifouling paint over 5 coats of epoxy primer
• Deck - white gelcoat with white color non-skid
• Exterior lighting - Cantalupi
• Gate doors at foredeck, both sides on aft deck and to swim platform, FRP
• Hatch - flush FRP on aft deck with S/S ladder down to lazarette
• Hatch - S/S gramed plexi-glass on fore deck
• Hatches - flush FRP over chain locker
• Hawser holes - S/S w/cleats
• Hull and deck house side: white gelcoat
• Portlights - S/S framed tempered glass with screens
• Safety package: USCG safety package included
• Sunbrella furniture fabric for Portuguese seats
• Watertight doors on both sides of pilothouse and transom – FRP

COCKPIT

• 5’ sports cockpit with storage hatch
• Gate door from the swim platform
• FRP built-in swim platform
• Stainless steel removable swim ladder on swim platform
• 2” 316 stainless steel removable safety rails on swim platform
• Deck scuppers piped out through transom at boot stripe
• Transom shower in recessed box with hot and cold water supply
• Fresh water wash down outlet
• One (1) LED courtesy light with two (2) two-way switches
• One step up to aft deck

FLYBRIDGE

• RIB Tender with Yamaha 4 Stroke (light use)
• FRP Cabinets on starboard side
• Davit - 1000lb hydraulic luff and manual rotation
• Exclusive Deluxbridge, full beam width all the way fwd, above the pilothouse
• Gate door to boat deck
• Bench seat L-shape FRP with storage beneath and FRP fixed table on port side
• Instrument console molded FRP
• Radar arch hinged FRP with two (2) deck lights
• Two halogen lights with FRP cover on radar arch
• Safety rails - S/S on flybridge/boat deck
• Sliding hatch and stairs down to pilothouse
• Steering wheel S/S destroyer
• Stidd helm seat, model 500N low back slimline series w/powder coated base and Naugahyde
• Sunbrella furniture fabric for flybridge cushions
• Venturi windscreen with stainless steel grab rails

INTERIOR IN GENERAL

• Appliances - GE Profile package
• Corian countertop in galley (including backsplash) and heads with S/S sinks
• Cushions w/muslin cover for berths and seats
• Drawers finished with formica, including guides and stops
• Hanging lockers with automatic lighting
• Headliner - removable foam backed fire resistant vinyl
• Light valance in salon and staterooms
• L-shaped settee in salon with 5" foam seats
• Reading lights in master stateroom, Cantalupi chrome
• Reading lights in VIP, Guest and crew staterooms, Cantalupi chrome
• Salon includes: entertainment center, (1) free standing coffee table and (1) end table
• Satin varnish on interior teak
• Shower lighting: Cantalupi
• Shower wall panel is off-white FRP
• Stidd helm seat, model 500N low back slimline series w/powder coated base and Naugahyde
• Teak and holly cabin sole at galley, pilothouse and heads
• Teak cabin doors and cabinets doors
• Teak veneer panel/vinyl coverings on bulkhead
• Wallpaper on walls in heads supplied by ORY

APPLIANCE PACKAGE

• GE Profile Counter-depth Energy Star 23.2 Cu Ft stainless-wrapped side-by-side refrigerator
• GE Profile built-in dishwasher
• GE Profile spacemaker 1.8 cu ft XL 1800 Microwave Oven with Recirculating Venting
• GE Profile 30" drop-in electric range with PreciseAir convection system
• GE Built-in 12" compactor
• GE 1hp continuous feed disposer
• Bosch Axxis series washer
• Bosch Axxis series vented dryer
• Bosch stacking kit with pull out tray
• U-Line combo ice maker/refrigerator combines maximum ice production with the performance of a high efficiency refrigeration system
• GE Monogram 27" outdoor cooking center

ENTERTAINMENT PACKAGE

• 37' flat screen with full HD for the salon
• 20"  LCD flat screen for the master stateroom
• Two 15" LCD flat screens - one (1) for the port staterooms
• A Bose Lifestyle 18 Home Entertainment system

OPTIONAL EQUIPMENT AND UPGRADES

• Village 220 volt  800 GPD water maker
• Glendinning engine control in lieu of standard Morse
• Groco 24v fuel transfer pump
• Two halogen lights with FRP cover on radar arch
• Search light: ACR model 100D 24v dc with dual station controls
• Handheld remote control on foredeck for windlass
• "Vimar" switches and outlets in lieu of standard
• Nutone central vacume system
• Upgrade to "Exalto" windshield wipers (3 sets)
• Upgrade standard lead-acid batteries to AGM
• Stainless steel breast plate on bow
• Add SS handrail on top of bulwark on both side and portuguese
• Add SS cover for port light
• Add gate door at port and stbd side on upper deck adjacent to pilothouse
• Add aft deck seat
• Extend swim-platform by 12"
• Wing door on aft deck (port and starboard)
• Add half-round overhead treatment over bed in master stateroom
• Teak panel on wall in heads in lieu of ORY supplied wall paper
• Add teak handrail on centerline of ceiling at salon
• Teak on swim-platform
• Teak on extended 12" swim platform
• Hard-top over flybridge
• Bilge blower
• Second 12kw Northern Lights generator
• Chilled water A/C
• 10" 16hp ABT bow and stern thruster with hydraulic windlass
• Charles ISO boost transformers in lieu of standard
• Two (2) 150 gallon fuel tanks in lazarette with valving and plumbing
• Granite counters in galley in lieu of Corian
• Raymarine Electronics package x 2
• Interior decor package
• Line cutters on shafts ( not being used)
• Maxwell HWC3500 hydraulic dual capstan windlass for dual anchors
• Polished 75lb SS anchor in lieu of standard galvanized anchor
• Additional 110lb SS anchor with 300' 3/8" chain
• Shoji screens in master stateroom over bed
• Maple burl accents in salon on window posts with 4 lights installed on dimmers
• Glendinning handheld remote engine and thruster controls with 3 plug in receptacles
• Install "Sikaflex" rubber in lieu of holly on all interior teak floors
• Flat screen TV's and Bose Lifestyle entertainment package installed at yard
• Teak combing around cockpit
• Rod holders in cockpit
• Appliance upgrades
• Spare set ZF propellers
• 2 Cafrano fans in pilot house
• Sony AM/FM Stereo with CD in pilothouse plus 2 sets Fusion speakers
• 2 outdoor stereo  speakers aft deck

UPDATED ELECTRONICS PACKAGE

• Raymarine E120 x 2 at lower helm
• Raymarine E120 on bridge
• Simrad Autopilot
• Raymarine Weather
• Raymarine VHF x 2 Inverter Wind, Speed and Depth Instruments
• Satellite TV with 4 Receivers
• Second independent Raymarine W90 radar/GPS, antenna in dome enclosure
• Skymate tracking/email/weather unit in pilot house

DISCLAIMER

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
